2020B Lathe, 2HP, 1 or 3PH, 220V
Description
The features you love on the 3520B Lathe are now available in a smaller footprint. The PM2020 Lathe is perfect for turners short on space, or projects where a short bed is convenient. Like its big brother, the PM2020 features a sliding headstock, electronic variable speed with low and high speed ranges, and the spindle lock. The enhanced features include a digital RPM readout, built in spindle indexing on the head stock, and a re-designed tailstock with internal storage, chrome trimmed handwheels, and a laser etched quill which is self-ejecting. Additional features include a two position mount for the optional bed extension, a sliding hammer knockout rod with brass tip, an attached tool caddy and a metal shelf for tool storage.
Specifications
Manufacturer | PowermaticC |
Model | PM2020 |
Condition | New |
Stock Number | PM9-1792020 |
Bed Construction | Cast Iron |
Distance Between Centers (In.) | 20 |
Motor Amps | 6.2 |
Motor (HP) | 2.0 |
Motor Phase | 3 |
Motor Power (HP) | 2 |
Motor Voltage (V.) | 220 |
Prop 65 | Cancer and Reproductive Harm |
Recommended Circuit Size (Amps.) | 20 |
Shipping Dimensions (L x W x H) (In.) | 55-1/8 x 27-1/4 x 30-5/8 |
Swing Over Bed (In.) | 20 |
Warranty | 5 Year |
Gross Weight | 582.0 |
Net weight | 530.0 |
