6" Jointer with Helical Head, 1HP 1PH 115/230V (54HH)
Description
This 6" Jointer features a helical cutterhead with 40 four-sided, indexable carbide inserts, delivering a superior finish and quieter operation compared to conventional cutterheads. The inserts require no adjustment once installed—simply rotate for a fresh edge if one becomes nicked.
Oversized infeed and outfeed tables are mounted on dovetailed ways, and the 38" fence includes positive stops at 90° and 45° (both right and left). The infeed table's fine/quick adjustment lever allows for fast, precise depth-of-cut settings. Powered by a 1 HP motor and a non-slip V-belt drive, this jointer offers maximum performance. The 4" dust port connects easily to any dust collection system.
Specifications
| Manufacturer | PowermaticC |
| Model | 54HH |
| Condition | New |
| Stock Number | PM9-1791317K |
| Warranty | 5 Year |
| Type of Cutterhead | HELICAL |
| Cutterhead Diameter (In.) | 2-1/2 |
| Maximum Cutting Depth (In.) | 1/8" |
| Cutterhead Speed (RPM) | 6000.0000 |
| Cutting Capacity (W x D) (In.) | 6 x 1/2 |
| Dust Collection Minimum CFM Required (CFM) | 450 |
| Dust Port Outside Diameter (In.) | 4 |
| Infeed Table Length (In.) | 32-1/2 |
| Number of Knives | 40 |
| Motor Power (HP) | 1 |
| Motor Voltage (V.) | 115/230 |
| Prewired Voltage (V.) | 115 |
| Motor Phase | 1 |
| Motor Amps | 13/6.5 |
| Gross Weight | 336.0 |
| Net weight | 317.0 |
| Prop 65 | Cancer and Reproductive Harm |
