Multi-Purpose DRO Gauge | B-MEASURE-SC+

or
Call (954)444-4004

Description

  • Snap-check digital gauge
  • For jointer, table saw, or router
  • Magnetic base
  • 2" max range

    • Use Baileigh industrial's Snap Check Plus Height Gauge to ensure precise setup of jointer and planer blades, and precise depth of cut settings on your table saw or router table. You can also use it to measure up to 1/4'' of slot or dado depth on your projects. When used for jointer setup the magnetic base and spring-loaded plunger let you ''snap'' the gauge in place on the jointer table, leaving your hands free to adjust the knives. The large LCD display is easy to read, and can be set for imperial, metric or fractional readings.
    For more information contact a rep at 920-717-1266 today!


  • Easy-read display can be reversed for right- or left-handed use
  • Smooth, spring-loaded plunger movement
  • Flat and ball tip anvils included
  • Super strong rare earth magnets in base for hands-free use
  • Humidity- and dust-resistant for long life in woodworking applications
  • 3-Way Reading Resolution: 0.0005", 0.1mm, 1/64"
  • Measuring Depth Range: 0-16"/0-400mm
  • Indicator Travel: 1"/25.42mm and Accuracy: ±0.01"
  • Auto shut off helps preserve battery life
  • Uses 1 3V CR2032 (included)

    • Show All

    Specifications

    ManufacturerBaileigh
    ModelB-MEASURE-SC+
    ConditionNew
    Stock NumberBA9-1225321
    Accuracy+/-0.001"
    ConstructionPlastic and Metal
    Included ToolingFlat and Ball Anvil
    Prop 65Cancer and Reproductive Harm
    Range of Measurement1/4 to 2"
    WarrantyNo value
    Gross Weight2.0
    Net weight2.0

    Documents
